Who knows what lurks in the mind of the manufacturer?
Both seem to have the standard rear springs, so would need my overload set for a tractor unit. I just added them to Cults - 👽 Chevy overload springs and towing pintles 1/35・ STL File for 3D printing・Cults
Can someone identify this truck in use by the 93rd Infantry Division ? This division had used the Chevy.
Not exactly a lot to go on there! My guess would be a CCKW based on the attachments on the axle - a Chevy would have had leaf springs visible in that pic.
Also, it has a Timken split axle as fitted to half of all CCKWs, with that big flange around the diff. Chevies used an axle similar to the “corporation” axles on CCKWs where the casing was a single piece with the rear face a separate part for access to the diff gears. So it’s a CCKW in that pic…
Banjo axles.
Yup, that’s he nickname for the GMC corporation axle!
Bravo, This vehicle looks awsome!
Welcome to Armorama!
Thank you all,
Back to the kitchen, is someone know if another truck than the CCKW can be used for a kitchen truck ?
In theory any truck could be used, but the space inside might be a bit more cramped. All of the gear is portable so the truck could just be used to move it from A to B and then it gets unloaded into a tent. The Chevy was more prevalent in the PTO, so maybe they used them there for kitchens?
The idea is to use the kitchen inside the truck as on the boxart of the ICM kit.
It could be done, but there would be a bit less elbow room so maybe not as many cooks working inside at one time? I haven’t seen any pics of a kitchen in a Chevy, but then again I haven’t seen many WW2-era field kitchen pics at all.
To completely disprove it, a historian would have to locate a definitive military directive that explicitly stated, “Do not, under any circumstances, put a field kitchen in a Chevrolet G506/G7117.” Because a document like that probably doesn’t exist, you can’t definitively prove it never happened. In the field, As I’ve shown time and time again (when someone starts quoting the TMs and FMs) GIs routinely modified vehicles based on immediate needs.
Thats said, Tom has a point - The standard US Army field kitchen had three field ranges, immersion heaters, and water/food storage. The GMC CCKW-353 had a 9-foot long, 80-inch wide bed . The Chevrolet G7117 was a smaller 1.5-ton truck with a tighter 70-inch wide bed. .Fitting three stoves across the front or sides would leave very little room for a 2-to-3-man cooking crew to safely work without burning the crap out of themselves.
Which would explain why maybe there was such a directive after all. Not a TM per se, but a local comander’s guiidance prohibiting jackassery.
I guess other 2½-ton 6×6 trucks could have been used as well, like the Studebaker US6 or the International M-5H-6 (yet to be released in 1/35 scale…)
H.P.
Possibly - except I thought most Studers went to Lend Lease? Those in US use as trucks (not tractors) seem to have been used on bases that had proper mess halls as far as I’ve seen.
Indeed…I was thinking more about the feasability of the conversion.
H.P.
Well, the dimensions of the load bed were the same as the CCKW, so it would be just as possible.
