Tamiya PE set 35209

Hi guys,

A blast from the past, but i have a question about Eduard #35209 for Tamiya 25 mm Bushmaster.
On page 2 you have some PE for the inside of the doors, but what means A en B ?
There is nothing to see on the instructions from Tamiya.
Does anyone knows what A en B means ?

TIA !

1 Like

They are trying to show two different patterns of how the L bracket should be placed in this locations.

That said, I get the concept but not the why is not along the post, seems backwards to me.

1 Like

If I were you I would adapt the RED-T turret to a current Tamiya HMMWV. Tamiya uses the early Italei HMMWV parts, which are obsolete now. Unfortunatly there is not much on the vehicle on the internet, I myself found only one or two outside pics in my bookshelf.

1 Like

Tank-1812,
Thank you for your reply.

H-H,

Too late, model is almost done. I changed the wheels and the frontbumper.

Thanks, Gé

2 Likes

Hi Ge, if you don´t mind, i´d like to see the finished model here. I had the kit once, but it went lost in my last move.

1 Like

DoD image of the Remote Electric Drive-Turret HMMWV.
